| Model | BYC-007SD1 | BYC-010SD1 | BYC-013SD1 | BYC-017SD1 | BYC-021SD1 | BYC-030SD1 | BYC-035SD1 | BYC-030SD3 | BYC-035SD3 |
| Heating Capacity — Air 26°C / Humidity 80% / Water 26°C in, 28°C out | |||||||||
| Heating Capacity (kW) | 7.6–1.7 | 9.5–2.3 | 13–3.0 | 17–3.8 | 21–4.8 | 28–6.8 | 35–8.8 | 28–6.8 | 35–8.8 |
| Power Input (kW) | 1.12–0.11 | 1.40–0.15 | 1.91–0.19 | 2.5–0.24 | 3.09–0.30 | 4.12–0.43 | 5.15–0.56 | 3.97–0.43 | 5.15–0.56 |
| COP | 15.8–6.8 | 15.8–6.8 | 16–6.8 | 15.8–6.8 | 15.8–6.8 | 15.8–6.8 | 15.8–6.8 | 15.8–6.8 | 15.8–6.8 |
| Heating Capacity — Air 15°C / Humidity 70% / Water 26°C in, 28°C out | |||||||||
| Heating Capacity (kW) | 6.1–1.4 | 7.6–1.9 | 9.8–2.3 | 13.5–3 | 16.5–3.8 | 23–5.5 | 25.5–6.4 | 23–5.5 | 25.5–6.4 |
| Power Input (kW) | 1.24–0.18 | 1.55–0.25 | 1.96–0.30 | 2.76–0.39 | 3.37–0.5 | 4.7–0.72 | 5.2–0.84 | 4.7–0.72 | 5.4–0.84 |
| COP | 7.6–4.9 | 7.6–4.9 | 7.6–5 | 7.6–4.9 | 7.6–4.9 | 7.6–4.9 | 7.6–4.9 | 7.6–4.9 | 7.6–4.9 |
| Cooling Capacity — Air 35°C / Water 29°C in, 27°C out | |||||||||
| Cooling Capacity (kW) | 4.2–1.0 | 5.3–1.3 | 7.2–1.7 | 9.4–2.1 | 11.6–2.7 | 14.9–3.8 | 19.3–4.9 | 14.9–3.8 | 19.3–4.9 |
| Power Input (kW) | 1.11–0.15 | 1.4–0.19 | 1.89–0.25 | 2.47–0.31 | 3.05–0.4 | 3.92–0.57 | 5.08–0.73 | 3.92–0.57 | 5.08–0.73 |
| EER | 6.6–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 | 6.7–3.8 |
| General Data | |||||||||
| Power Supply | 220–240V/1/50Hz | 220–240V/1/50Hz | 220–240V/1/50Hz | 220–240V/1/50Hz | 220–240V/1/50Hz | 220–240V/1/50Hz | 220–240V/1/50Hz | 380–415V/3/50Hz | 380–415V/3/50Hz |
| Max Power Input (kW) | 1.55 | 1.78 | 2.2 | 2.6 | 3.2 | 4.55 | 4.76 | 6.43 | 6.93 |
| Max Current (A) | 7.3 | 8.3 | 10.2 | 12 | 14.7 | 20.4 | 30 | 7.9 | 11.3 |
| Water Flow Volume (m³/h) | 2.5 | 3.5 | 4.5 | 5.5 | 6.5 | 9 | 12 | 9 | 12 |
| Refrigerant | R32 | ||||||||
| Heat Exchanger | Titanium | ||||||||
| Air Flow Direction | Horizontal | ||||||||
| Automatic Defrosting | By 4-way valve | ||||||||
| Working Temp. Range (°C) | −15–43 | ||||||||
| Casing Material | ABS | ||||||||
| Waterproof Level | IPX4 | ||||||||
| Noise Level 1m (dB(A)) | 39–49 | 40–52 | 42–53 | 43–55 | 45–56 | 47–58 | 49–59 | 47–58 | 49–59 |
| Noise Level 10m (dB(A)) | 20–29 | 20–32 | 22–33 | 23–35 | 25–36 | 27–38 | 29–39 | 27–38 | 29–39 |
| Net Weight (kg) | 42 | 43 | 53 | 54 | 58 | 88 | 98 | 88 | 98 |
| Gross Weight (kg) | 53 | 54 | 64 | 65 | 69 | 99 | 110 | 99 | 110 |
| Net Dimensions (mm) | 864*349*592 | 864*349*592 | 925*364*642 | 925*364*642 | 925*364*642 | 1084*399*737 | 1084*399*737 | 1084*399*737 | 1084*399*737 |
| Package Dimensions (mm) | 930*400*640 | 930*400*640 | 990*435*760 | 990*435*760 | 990*435*760 | 1146*460*862 | 1146*460*862 | 1146*460*862 | 1146*460*862 |
